| Inner diameter () | 26 |
| Outer diameter () | 34 |
| Material | copper |
| Thickness (mm) | 2 |
| Din/iso | 7603 |
| Shape | a shape |
| Cross-sectional form sealing ring | a shape |
| Goods tariff number | 7415210000 |
| Outer diameter (mm) | 34 |
Expresslevering
| Manufacturer | Model | Version | Engine code | Construction type | Construction start | Construction end | Pk | Power kw |
| Manufacturer | Productnumber |
| MERCEDES-BENZ | 007603 026109 , 007603026109 |
| DAF | 0331 341 , 0331341 |
| MAN | 06.56190.0727 , 06561900727 |
| PORSCHE | 900 123 084 20 , 90012308420 |
| RENAULT TRUCKS | 50 00 254 870 , 5000254870 |
| MAGIRUS-DEUTZ | 0111 8768 , 01118768 |
| DEUTZ | 0111 8768 , 01118768 |
| HANOMAG HENSCHEL | N 007603 026109 , N007603026109 |
| HANOMAG | 0996 731 023 , 0996731023 |
| MASSEY FERGUSON | 3007 190 X1 , 3007190X1 |
| Usage numbers |
| EL031046 |
| 31.046 |
| 4 |
| 04125E+12 |
The Seal Ring (031.046) creates a pressure-tight seal between critical mechanical components. Replacing it with a Porza-quality seal ring restores leak-free operation and long-term system reliability.
A seal ring is a component used to create a tight seal between two connected parts. Its function is to prevent leaks of fluids or gases and protect systems from contaminants such as dirt and moisture.
Key specifications include inner and outer diameter, thickness, material (such as rubber, FKM, PTFE, or metal), temperature resistance, pressure rating, and compatibility with the specific system. It must withstand the operating conditions of its application.
Replacement is necessary when the seal is worn, hardened, cracked, or leaking. It is also recommended to replace seal rings during maintenance or whenever components are disassembled.
Porza offers a fit guarantee option where your vehicle details are checked against product specifications to ensure correct compatibility.
Porza provides high-quality sealing components with fast delivery across Europe and options for online ordering or in-store pickup.
If the fit guarantee is selected, compatibility is verified before shipping. If the product does not fit, it can be returned according to the return policy.
